Project 2: Contextual Fit
Architectural Design II - ARC 257

In Project 2,we are tasked with designing an addition to the Smith house, built in 1965 by architect Richard Meier. this new design must respect the original architect by analyzing and incorporating its existing systems and patterns.

we are also asked to develop a concept that responds to the home owners current needs ,while introducing new elements or systems not found in the original house

Narrative

The Smith family enjoys strength training and martial arts, but right now, Mrs. Smith and Mr. Smith have to use a different room while the kids play in theirs. To fix this, they've decided to add onto their home. They want a larger exercise room where they can game without having to go elsewhere. Mrs. Smith has also asked for a family room and more outdoor space for family activities.

Hierarchy : Exercise Room

Meta idea : Trapezoidal Weight

Sorting Of Space

Public

Patio

Dinning room

Kitchen

Living room

Family room

Roof deck

Exercise room

Goup

Exercise Room

Patio & Roof Deck

Family Room

Private

Master Bedroom

Master Bath

Bathrooms

Individual

Master Bedroom

Master Bath

Bathrooms

Existing Floor Plans

Existing Buildings Systems & Patterns

Final Floor Plan

LOWER LEVEL

MIDDLE LEVEL

UPPER LEVEL

New Floor Plan Analysis

Preliminary Design

The following designs are preliminary designs mapping out the requested spaces as mass and paths of circulation. After observing the design and circulation of these designs i choose design 3 as i believe it had the most potential.
